KOMPAS-3D v23.0.3 Win x64

ASCON 打造了功能強大的 KOMPAS-3D 設計系統，可管理包含數千個來自標準庫的子裝配體、零件和對象的項目。它為您提供當今中級 CAD/CAM 程序中標準的所有 3D 建模功能。

實體建模

實體建模通常從繪制 2D 草圖對象開始，然后將其轉換為 3D 零件，使用約束固定它們，按指定距離拉伸它們，繞軸旋轉它們等等。

您可以使用編輯命令進一步細化 3D 零件，這些命令可以添加倒角和圓角、切割孔、添加加強筋等等。

要?jiǎng)?chuàng)建復雜的裝配體，您可以使用規則和 3D 約束將多個零件連接在一起。

曲面建模

曲面模型通常從創建由各種曲線、空間線和點組成的 2D 和 3D 輪廓開始。

然后，您可以通過拉伸、旋轉和沿路徑生成它們來創建 3D 曲面；通過定義曲線的截面和網格等。您可以通過修剪、分割、延伸和恢復表面，或通過添加切口等方式進一步細化表面。

當您為表面分配厚度和材料時，KOMPAS-3D 會將表面轉換為實體模型。

鈑金建模

KOMPAS-3D 使用其鈑金功能設計各種鈑金零件、儀表包、電氣柜、支架等。

您幾乎可以設計任何可以通過鈑金成型（如彎曲和沖壓）生產的產品。

設計完成后，您可以通過從鈑金零件生成尺寸平面圖來準備生產鈑金零件。

對象建模

無需繪制草圖和建模零件，而是借助預繪制的對象更快地將它們添加到裝配體中。您可以使用基于典型工業零件（如管道、齒輪、緊固件和其他金屬形狀）的對象快速進行設計。

KOMPAS-3D 提供可以快速修改的對象，了解如何與模型中的其他零件互動，并存儲有關自身的有用信息。

ASCON forged the KOMPAS-3D design system to be so powerful that it manages projects with thousands of sub-assemblies, parts, and objects from standards libraries. It provides you with all the 3D modeling capabilities that are standard among mid-level CAD/CAM programs today.

Solid Modeling

Solid modeling typically starts by drawing 2D sketch objects, which you turn into 3D parts fixing them with constraints, extruding them by specified distances, rotating them about their axis, and so on.

You further refine 3D parts with editing commands that add chamfers and fillets, cut holes, add stiffeners, and much more.

To create complex assemblies, you join multiple parts together with rules and 3D constraints.

Surface Modeling

Surface models typically begin with the creation of 2D and 3D profiles made from all sorts of curves, spatial lines, and points.

You then create 3D surfaces by extruding, revolving, and generating them along paths; by defining sections, and grids of curves; and more. You can further refine surfaces by trimming, splitting, extending, and restoring them; by adding cutouts to them; and so on.

KOMPAS-3D turns surfaces into solid models when you assign thicknesses and materials to them.

Sheet Metal Modeling

KOMPAS-3D designs all kinds of sheet metal parts, instrument packages, electrical cabinets, brackets, and so on with its sheet metal functions.

You can design practically anything that can be produced by sheet metal forming like bending and stamping.

Once your design is complete, you prepare sheet metal parts for production by generating dimensioned flat patterns from them.

Object Modeling

Instead of drawing sketches and modeling parts, image adding them to assemblies much more quickly with the assistance of pre-drawn objects. You design rapidly with objects based on typical industry parts, such as pipes, gears, fasteners, and other metal shapes.

KOMPAS-3D offers objects that can be modified quickly, understand how to behave with other parts in models, and store useful information about themselves.
